Inductive Magnet Stirrer IMS mini Set

Inductive Magnet Stirrer IMS mini Set

EMC-20043066

€839,60
€839,60
Sale Sold out
W006

Miniaturized, wear-free magnetic stirrer with four cuvettes, stirring volume up to 25 ml. Ideal size for system integration e.g. in photometers. Extremely robust construction, easy to clean, maximum resistance, submersible up to +50°C. Fully encapsulated and hermetically sealed stainless steel housing, IP68, water-, dust-, and germproof. Including C1 controller featuring SoftStart for reliable catching/centering and safe acceleration of the stirring bar.

Model IMS mini
Stirring points 1
Stirring volume 1-25 ml
Stirring power (max.) 10 W
Dimensions (WxDxH) 13x13x6 mm
Housing material PUR
Operation conditions -10°C up to +50°C in air / up to +50°C in water
Operation voltage (max.) 48 VDC
Protection category IP68
Weight (gross) 0.1 kg



 Model C1 Controller
Speed range 120-1,200 rpm
Stirring power (max.) 10 W
Dimensions (WxDxH) 65x50x45 mm
Housing material Plastic
Operation conditions  0°C up to +40°C / 80% H
Electrical data 100-240 V/ 50-60 Hz/ 0.75 A
Protection category IP20
Weght (gross) 0.5 kg
View full details

Made in Germany

Our spectrophotometers are built and calibrated in our headquarters in Duisburg, Germany. Every instrument is being tested and checked before being packed and shipped to our customers.

Versatility

The compatibility with our magnet quick change cell holder system ensures maximum versatility.
