Hotplate 15

Stirring hotplate 15, incl. external controller, suitable for 15 x 250 ml beaker glasses (tall form), heating up fast

Stirring
Powerful 15 stirring points, maintenance-free and wear-free by inductive EMCLAB-Magnetic-Drive concept, extremely wide speed range of 100 to 2,000 rpm, 100% synchronized speed, jerk-free stirring even at low speeds, 10-step power setting of the stirrer, high power setting for viscous liquids and reduced stirring power for long-term operation without any heating effects caused by the stirrer. Clear digital display for setting stirrer speed, stirrer power and temperature of the integrated heater, SoftStart for reliable catching/centering and safe accelerating of the stirring bar.
Heating
Heating plate made of resistant aluminium alloy, PTFE-coated for increased chemical resistance and easier cleaning, fast heating-up by powerful integrated electrical heater, homogenous temperature distribution, maximum heating temperature +200 °C, PowerDetect for automatic compensation of stirring power loss, caused by heating, which can reach up to 40% at high temperatures, independent over-heating protection inside the plate.

Including separate controller for operation of magnetic stirrer and integrated heater, for long-term protection of the electronics against aggressive liquids and gases as well as thermal influences, stainless steel housing.


Model	Stirring hotplate 15
Stirring points	15
Stirring point distance	65 mm
Stirring volume/point	1 - 1,000 ml
Stirring power (max.)	40 W Power setting 4 - 40 W (10-step)
Temperature (max.)	+200°C
Speed range	100 - 2,000 rpm
Dimension (WxDxH)	250x430x75 mm
Heating power (max.)	1,200 W
Operation voltage (max.)	230 V
Protection category	IP20
Weight (gross)	15 kg
